Safety instructions J
Cannot chafe.
Fig. 6 Secure that crossing hydraulic lines cannot chafe
RIGHT
WRONG
J
Are not kinked.
J
Do not have to withstand tensile strains.
J
Are protected against thermal radiation.
J
Are accessible at all times.
Push hydraulic hoses into the sockets only by hand. Never try to drive the hydraulic hoses in with a tool as this will damage the connections. When installing the hydraulic hoses, ensure that they cannot be: J
Torn out,
J
Kinked,
J
Crushed,
J
Driven over or
J
twisted by the movement of the shield (Fig.: 7).
Fig. 7
Hydraulic hoses must not be twisted caused by moving parts of the shield support
RIGHT
2.12
WRONG
