Replacement of wear parts_________________________________________ Conveyor power unit The conveyor power unit (Fig. 94) has been assembled as a unit and can be removed and installed as a unit. The power unit consists of the following main components: ■
electric motor (125 hp)
■ coupling ■
connecting tube
■
Open loop load sense pump
Fig. 94: Conveyor power unit Electric motor
Connecting tube Lock washer
Motor mount (Bolt, washer, and lock nut) Coupling
Flat washer
Flat washer Hex head bolt
Hex head bolt
Lock washer
Open loop load sense pump
________________________________________________________________ 5.148 FB110 Feeder Breaker
