Bucyrus International, Inc. 495HR Electric Mining Shovel
COLLECTOR RINGS High voltage collector rings between the revolving frame and truck frame transfer electric power from the truck frame to the rotating deck. Electric power enters the truck frame between the propel motors and is transferred by means of collector ring shoes to the collector rings. The shoes are mounted between the cast center pintle hub and the swing rack.
April 2006
21
Manual No. 10403
