3BInstallation
Edition 06.2010
Fig. 4.3
4.3
Detail of the accessories pack drawing, connection diagram for crowd or propel motor
•
The additional terminal box is mounted as described in document no. A5E03039147A.
•
The pin assignment of the signal lines is shown in dimension drawing A5E02610781A.
Commissioning During and after installation, verify, among other things, that: •
All screws, connecting elements, and electrical connections of all connections made are tightened to the specified torques and locked in the required way.
•
The equipotential bonding connections have been properly made.
WARNING The ground connection on the motor must have a bright surface!
•
The flow of cooling air is not restricted.
•
If the motor is started up after a storage period of two years or more, the bearings are regreased.
•
The terminal box has been closed and properly sealed.
Siemens AG 24 / 50
Three-phase motor
A5E02886353A Operating instructions
