2.1.1.2
1BTransport, storage
Suspending the motor vertically Note Remove any cover-up labels from the transport threads.
To transport the motor vertically, screw four M20 attachment elements according to DIN 5688 and DIN 5691 (quality class 8) into the holes in the stator frame at the N-end with a minimum reach of 30 mm. For more information about suspending the motor vertically, refer to Fig. 2.2. After the motor has been transported and the attachment elements removed, the threaded plugs must be resealed with cover-up labels. Danger Never stand underneath suspended loads! Incorrect suspension will result in serious injury or substantial property damage if proper precautions are not taken! CAUTION Individual motors are only allowed to be suspended from the main attachment elements provided for this purpose. These are designed to support the weight of the motor. Use suitable lifting gear (motor weight excluding mounting parts: Error! Reference source not found. kg; refer also to chapter Error! Reference source not found., Technical data). Any auxiliary attachment elements available, e.g. on bearing shields or elsewhere, are not designed to support the full weight of the motor. They are only suitable for lifting the various component parts during dismantling and assembly. Note Under no circumstances should steel ropes or chains be fastened around the motor.
