BUCYRUS INTERNATIONAL, INC. 182M Electric Mining Shovel
Operator Interface Unit Display Panel
NOTE: When using the NEXT SCREEN or PREVIOUS SCREEN in the various OIU displays, PREVIOUS SCREEN selects the last page in the program if the operator is currently on its first page and NEXT SCREEN selects the first page in the program if currently on its last page.
MASTERSWITCH REMOVAL OR REPLACEMENT The Masterswitches can be removed for servicing by removing 4 masterswitch mounting screws and opening the console. As the masterswitch is removed, feed the control wires into the masterswitch mounting bracket. NOTE: When replacing the masterswitch, make sure that the Y ("-") axis (cast into the mounting flange) faces forward. Refer to the Electrical Schematics, code No. 5P, for wiring diagrams.
