BUCYRUS INTERNATIONAL, INC. 182M Electric Mining Shovel
OPERATOR'S SEAT ADJUSTMENT The operator's seat was selected to give operators of all sizes the ability to position and adjust the seat to their preferred arrangement. Since the operator must sit for extended periods of time, it is worthwhile to adjust the seat to the most comfortable position. A.
WEIGHT COMPENSATOR - knob adjusts support coils tension to suit the weight of occupant. Use the knob to dial the weight of the operator (110 to 290 Lbs.) on the visual indicator next to it.
B.
HEIGHT - Vertical adjustment handle. Lift up to release.
C.
FORE AND AFT - Lift the lever bar at the front of the seat and move the seat forward or rearward as desired, releasing the lever at the desired location.
D.
BACKREST TILT - angle of the backrest is adjustable from vertical by lifting the lever up on the left side to release the backrest.
