Operators Manual BI010977
Propel Motion Propel motion is controlled by placing the propel transfer switch in the propel mode and actuating the left or right joystick. To propel in a straight forward direction, push forward on both the left and right joysticks at the same time. The speed is increased as the levers are displaced farther from neutral. To propel straight in reverse, pull equally both joysticks to the rear. NOTE: The control stop pushbutton must be pressed before the propel transfer switch can be activated.
THE HOIST BRAKE MUST BE SET WHENEVER IN THE PROPEL MODE.
Propel - Straight Forward/Reverse
OM11096-EN
7295 Electric Rope Shovel
97 October 2012
