OPERATING INSTRUCTIONS RH 400 Operation Passenger seat
Adjusting the seat cushion
The passenger seat (Fig. 2-24:) can be adjusted in inclination, height and fore-and-aft position. The seat suspension can be adjusted to suit the passenger's weight.
Adjust the seat cushion inclination by pulling the handle (4) upwards. Bring seat cushion into the desired position by moving the body forwards or back. Release handle (4).
Adjusting the armrests The armrests can be raised and lowered as required. To adjust the inclination of the armrests, turn knobs (6) clockwise or counter-clockwise.
Fore-and-aft adjustment The fore-and-aft position is adjusted with lever (1). Pull lever (1) upwards, slide seat into the desired position and engage the lever (1).
Adjusting the seat suspension The seat suspension can be continuously adjusted with the handwheel (2). Higher weight - turn handwheel (2) clockwise (hard springs). Fig. 2-24:
Adjusting the backrest
Lower weight - turn handwheel (2) counterclockwise (soft springs).
The backrest inclination can be adjusted by pulling the handle (5) upwards. Lean against the backrest to move it to the desired position. Release handle
The value on the handwheel scale and the weight of the passenger should be coordinated (optimum suspension).
2-19
BA RH400(3 659 450.00)-EN
