OPERATING INSTRUCTIONS RH 400 Inspection and servicing Filling up the grease container
Breather filter
Fill up the grease container through the service station (Fig. 3-132:).
Check/change the breather filter at regular intervals.
The use of the hose is described in the chapter "Flexible hose for the change of oil and cooling water"
Ü Unscrew wing nut (10, Fig. 3-133:).
Ü Switch on the indicator system with toggle switch (33, Fig. 3-132:). Ü Unscrew the cap of the express coupling (11).
Ü Withdraw cover (7, Fig. 3-134:) and filter element (8). Ü Check filter element. Replace if necessary. Ü Re-install breather filter.
Ü Connect the filling hose of the service vehicle. Ü When the grease container is full, the indicator lamp (34) lights up. Ü Remove the flexible hose. The express coupling closes automatically. Ü Refit the protective cap.
Fig. 3-133:
Fig. 3-132:
Ü
Fig. 3-134:
3-101
BA RH400(3 659 450.00)-EN
