OPERATING INSTRUCTIONS RH 400 Inspection and servicing To clean the tracks:
CRAWLER TRACKS 3659732
Cleaning Clean tracks, track and support rollers, sprockets and idlers regularly and whenever required. Cleaning is especially important in winter to prevent §
the tracks from being thrown off
§
oil from leaking out of track and support rollers, sprockets and idlers
§
excessive wear
§
the track from breaking.
Ü raise one side of the excavator with the working equipment and allow track to turn; Ü clean the side member supporting the track; Ü clean track and support rollers (1 and 2 ,Fig. 3-117:) thoroughly; Ü clean the sliding planes on the idler guides.
Fig. 3-117:
3-93
BA RH400(3 659 450.00)-EN
