OPERATING INSTRUCTIONS RH 400 Inspection and servicing Drawing off cooling liquid
Filling in cooling liquid Ü Shut off the engines Fill in cooling liquid with the service station (Fig. 3-33:) through §
express coupling (2) for the lefthand cooling circuit
§
express coupling (3) for the righthand cooling circuit
Ü Unscrew cap of express coupling. Connect hose of the service vehicle.
Fig. 3-33:
The hose line and its use are described in the "hose line for oil and cooling liquid change" section.
The cooling liquid can also be drawn off with the service station (Fig. 3-33:) through
Ü Remove hose from express The coupling closes automatically.
§
express coupling (2) for the lefthand cooling circuit
Ü Screw on protective cap.
§
express coupling (3) for the righthand cooling circuit
Ü Unscrew cap of express coupling. Connect hose line of the service vehicle. The hose line and its use are described in the "hose line for oil and cooling liquid change" section. Ü Remove hose line. The express coupling closes automatically. Ü Screw on protective cap
3-49
coupling.
Testing the cooling liquid composition The engine operating instructions contain a detailed description of how to prepare and test the cooling liquid composition. In case of imminent frost check that the factory-adjusted anti-freeze concentration is sufficient for the expected temperatures. Check the cooling liquid in the cooling system regularly to ensure that the water filter replacement interval resp. the DCA4 mixture is sufficiently concentrated to prevent corrosion under the corresponding operating conditions.
BA RH400(3 659 450.00)-EN
