OPERATING INSTRUCTIONS RH 340 Operation
Assemblies resp. reservoirs
Measuring device
Remarks
Pump transfer gearbox
Dipstick (1, Fig. 2-65:)
Engine
Dipstick (1, Fig. 2-66:
Stop filling when the oil reaches the "max" mark on the dipstick (see Part 3, chapter "Pump transfer gearbox Checking the gearbox oil level/Filling in oil"). Stop filling when the oil reaches the "max" mark on the dipstick (see chapter "Engine - engine oil level/filling in oil").
Engine oil tank (Option)
Dipstick (2, Fig. 2-67:)
Stop filling when the oil reaches the "max" mark on the dipstick (see chapter "Engine - oil tank Checking the oil level in the engine oil tank/Filling in oil")
Fig. 2-67:
Fig. 2-65:
Fig. 2-66:
2-62
BA RH340(3 720 350.00)-EN
