OPERATING INSTRUCTIONS RH 340 Operation Fig. 2-55: No.
Element
Function
151 Warning lamp
Slewing pump contaminated
1 Lights up when the slewing pump is contaminated with metal particles.
152 Warning lamp
Slewing pump contaminated
2 Lights up when the slewing pump is contaminated with metal particles.
153 Warning lamp
Slewing pump contaminated
3 Lights up when the slewing pump is contaminated with metal particles.
154 Warning lamp
Slewing pump contaminated
4 Lights up when the slewing pump is contaminated with metal particles.
155 Warning lamp
Main pump 1 con- Lights up when the main pump is contaminated with metal particles. taminated
156 Warning lamp
Main pump 2 con- Lights up when the main pump is contaminated with metal particles. taminated
157 Warning lamp
Distributor gearbox Lights up when the distributor gearbox is 1 left contaminated contaminated with metal particles.
158 Warning lamp
Slewing pump temperature
1 Lights up when the temperature in the slewing pump is too high
159 Warning lamp
Slewing pump temperature
2 Lights up when the temperature in the slewing pump is too high
160 Warning lamp
Slewing pump temperature
3 Lights up when the temperature in the slewing pump is too high
161 Warning lamp
Slewing pump temperature
4 Lights up when the temperature in the slewing pump is too high
162 Warning lamp
Main pump 3 con- Lights up when the main pump is contaminated with metal particles. taminated
163 Warning lamp
Main pump 4 con- Lights up when the main pump is contaminated with metal particles. taminated
164 Warning lamp
Distributor gearbox Lights up when the distributor gearbox is 2 right contamina- contaminated with metal particles. ted
BA RH340(3 720 350.00)-EN
Symbol
2-51
