OPERATING INSTRUCTIONS RH 340 Operation Fig. 2-45:
No.
Element
Function
33
Buzzer (continued)
Gives an acoustic warning signal if a fault is reported !
Symbol
Engine oil level (engine 1 and / or 2; left and / or right) too low
!
Distributor gearbox (1 and / or 2; left and / or right) contaminated
!
Working pump (1, 2, 3, and / or 4; left and / or right) contaminated
!
Slewing motor (1, 2, 3 and / or 4) contaminated
!
Slewing circuit temperature (1 and / or 2) too high
!
Lubricating system pressure too low
!
Grease level in lubricating system too low
!
On-board voltage 24 V too low The buzzer (33) continues to sound until the fault has been retified.
34
Buzzer
BA RH340(3 720 350.00)-EN
Gives an acoutic warning signal when the stick/boom angle to too small.
