OPERATING INSTRUCTIONS RH 340 Inspection and servicing Hydraulic oil can also be filled in by means of the service station (Fig. 3-71:). " Unscrew cap of express coupling (10). Connect filling hose express coupling of the service vehicle. The use of the hose line is described in the "Hose line for oil and cooling liquid changes" section. " Fill in hydraulic oil until the oil level lies between the ½ and the ¾ marks of the inspection glass (1, Fig. 3-69:) (oil grade see "Refilling quantities - Oil"). " Unscrew the hose line; the express coupling closes automatically. " Screw protective cap back in place
Fig. 3-71:
BA RH340(3 720 350.00)-EN
3-71
