OPERATING INSTRUCTIONS RH 340 Inspection and servicing Water trap (option)
Servicing
Water contained in the fuel is removed by the water trap (Fig. 3-52:).
Draining off water Carry out the following works in accordance with the servicing schedule and at regular intervals: " Loosen venting plug (9, Fig. 3-53:) and leave drain valve (3) open until there is no more water in the diesel fuel flowing out of the valve.
Fig. 3-52:
Fig. 3-53:
Collect escaping liquid in a recipient suitable for diesel fuel and discard without polluting the environment.
The liquid flowing out of the valve flushes and cleans the filter element(6) von from top to bottom. " Close drain valve (3) and tighten venting plug (9).
BA RH340(3 720 350.00)-EN
3-61
