OPERATING INSTRUCTIONS RH 340 Inspection and servicing Radiators Risk of scalding from hot cooling liquid. Open radiator cap cautiously.
The radiators are located on the superstructure in the counterweight module. Weekly checks: " Check radiator fins for dirt and clean, if required.
" Turn radiator cap (1) back to the first notch.
Cooling-liquid level
" When the pressure has been released turn cap into the "open" position and remove.
An insufficient cooling-liquid level is displayed on the BCS screen (2, Fig. 3-30:).
The cooling-liquid level should reach up to the lower edge of the filler tube. Top up with cooling liquid, if required. The level indicator (4, Fig. 3-31:) shows the liquid level.
Fig. 3-30:
The radiator caps (1, Fig. 3-30:) are accessible from above. Fig. 3-31:
BA RH340(3 720 350.00)-EN
3-49
