OPERATING INSTRUCTIONS RH 340 Inspection and servicing Filling in engine oil
The hose line and its use are described in the "hose line for oil and cooling liquid change" section. " Start the engines and allow to run at idling for abt. 2 minutes. " Check oil level and top up with engine oil until the oil level has reached the mark on dipstick (2, Fig. 3-23:). " Remove the hose line. The express coupling closes automatically. " Screw on protective cap.
Fig. 3-22:
The engine oil is filled in with the service station (optional) (Fig. 3-22:) through !
express coupling (6) for the lefthand engine oil reservoir
!
express coupling (7) for the righthand engine oil reservoir
until the oil level has reached the mark on dipstick (2, Fig. 3-23:). Fig. 3-23:
" Unscrew cap of express coupling and connect hose line of the service vehicle
3-44
BA RH340(3 720 350.00)-EN
