OPERATING INSTRUCTIONS RH 30 F Inspection and servicing Cleaning the grease sieves Check the grease sieves (13, Fig. 3-97:) for contamination and clean, if required. The grease sieves must also be cleaned after a blockage in one of the grease lines has been removed
Cleaning Ü Loosen nut (12) by holding union (16) in place with a wrench. Ü Unscrew disk (14).
Lubricating the grease distributor of the working equipment Ü Withdraw protective cap from greasing nipple. Ü Clean greasing nipple. Ü Press nozzle of the grease gun onto the greasing nipple. Ü Inject grease until the fresh grease squeezes the used grease out of the bearing joints.
Ü Remove sieve (13) and clean with white spirit or paraffin oil.
Make sure that used grease emerges from all greasing points connected to the distributor.
Ü Refit (13) and fasten with disk (14).
Only then have all greasing points connected to the grease distributor been properly greased.
Ü Screw nut (12) onto the union.
Ü Wipe off used grease with cleaning rags. Ü After greasing, place protective cap back on the greasing nipple. Dispose of cleaning rags without polluting the environment.
Fig. 3-97:
BA RH30F(3 663 370.00)-EN
3-85
