OPERATING INSTRUCTIONS RH 340 Electric OPeration Taking on harness Take harness out of handbag (15, Fig. 2-45:).
Pull loop (6) of the back support (1) between your legs to the front (Fig. 2-47:). Pull loop (5, Fig. 2-48:) through loop (6).
Fig. 2-45:
Take on shoulder belts (2 and 3, Fig. 2-46:).
Fig. 2-48:
Pull loop (4, Fig. 2-48:) through loop (5). Press the hooking safety device (17, Fig. 2-48:) of the snap hook (16).
Fig. 2-46:
Pull back support (1, Fig. 2-46:) behind your body (Fig. 2-47:). The loops (4 and 5) are in front of your body. Fig. 2-49:
Fig. 2-47:
BA RH340(3 725 090.00)-EN
2-35
