OPERATING INSTRUCTIONS RH 340 Electric Inspection and servicing ON-BOARD CRANE (OPTIONAL)
Checking the on-board crane
Monitoring, warning and control elements
Extract from the inspection and testing regulations
(Fig. 3-120:)
The on-board crane is approved in accordance with the Accident Prevention Regulations for Cranes (VBG 9, applicable only in Germany).
The on-board crane must be inspected regularly in accordance with the regulations in force in the country of use. The inspections must be requested by the user of the crane. The expert or specialist entrusted with the inspection can be appointed at the user's discretion. The user must ensure, however, that the appointed person meets the requirements.
Fig. 3-120:
1
Monitoring lamp
alternator
2
Warning lamp
engine oil pressure
3
Warning lamp
engine temperature
4
Monitoring lamp
air filter
5
Key-switch
electrical system ON/OFF
6
Button
engine start
7
Monitoring lamp
preheating system (option)
8
Button
speed variation
9
Monitoring lamp
crane in operation
10 Warning lamp
malfunction
11 Button
EMERGENCY STOP
12 Button
emergency lowering of winch
21 Control lever
extending and retracting of boom extension
22 Control lever
folding the boom
23 Control lever
swing the boom
24 Control lever
winch ON/OFF
BA RH340(3 725 090.00)-EN
The user is obliged to make available all documents required for the inspection and to ensure the smooth running of the inspection. He is furthermore obliged to provide, if required, crane operators and auxiliary personnel and the required test loads. The result of the inspection is to be documented in an inspection record signed by the inspector. The inspection record serves as proof on the part of the user that the inspections have been carried out. The inspection record must contain all data required for crane identification and for the performance of further regular inspections.
3-99
