OPERATING INSTRUCTIONS RH 340 Electric Inspection and servicing OTHER MAINTENANCE
Equipment
Heating and air conditioning
Check the welded joins of the working equipment regulary.
Change the filter mats in the air suction regulary. The filter mats are located on the backside of the driver`seat.
Inspections must be carried out acc. to the "Structural Inspection Reports" every 500 OH and every 5000 OH. "Structural Inspection Report" forms for those inspections can be downloaded from the Terex O&K website, section "Support, Warranty". The inside located joins are accessible through the man-holes in stick (arrow, Fig. 3-115:) and boom (arrow, Fig. 3-116:).
Fig. 3-114:
Remove cover (1, Fig. 3-114:) Change filter mats (2) Fasten cover (1) again. Fig. 3-115:
Fig. 3-116:
3-96
BA RH340(3 725 090.00)-EN
