OPERATING INSTRUCTIONS RH 340 Electric Inspection and servicing Brake chamber - Changing oil
Breather filter
Draining off oil
Unscrew breather filter (1 and 5, Fig. 3-84:) and clean in white spirit or parafin.
Place a collecting recipient for used oil under the pre-chamber. Choose the required capacity in accordance with the "Refilling quantities - Oil" table. Unscrew drain plug (7, Fig. 3-84:) and drain off the oil completely. Slackening breather filter (5) allows the oil to run out more readily. Clean screw plug (7). Screw screw plug (7) back in place.
Fig. 3-84:
Filling in oil Unscrew screw plug (6). Fill in oil through opening of breather filter (5) until it flows out of opening in plug (6). Screw plug (6) and breather filter (5) back in place.
3-80
BA RH340(3 725 090.00)-EN
