OPERATING INSTRUCTIONS RH 340 Electric Inspection and servicing Pre-chambers working pumps, check oil level, filling in oil, draining oil, changing oil
Pre-chambers swing pumps, check oil level, filling in oil, draining oil, changing oil
Check oil level:
Check oil level:
Unscrew plugs (11, Fig. 3-73:) The oil level should be reach up to the lower edge of the opening. Top up with fresh oil if necessary.
Unscrew plugs (21, Fig. 3-74:) The oil level should be reach up to the lower edge of the opening. Top up with fresh oil if necessary.
Filling in oil:
Filling in oil:
Unscrew overflow (12, Fig. 3-73:). Fill in fresh oil through the opening until it runs out through the plug opening (11). (see Oil specification)
Unscrew overflow (22, Fig. 3-74:). Fill in fresh oil through the opening until it runs out through the plug opening (21). (see Oil specification)
Draining oil:
Draining oil:
Place a suitable receptacle for used oil under the plug (13, Fig. 3-73:). The required receptacle capacity is specified in the „Filling quantities – oil“ table.
Place a suitable receptacle for used oil under the plug (23, Fig. 3-74: The required receptacle capacity is specified in the „Filling quantities – oil“ table.
Unscrew plug (13) and allow oil to drain. Screw in plug and fill in oil after repair work has finished.
Unscrew plug (23) and allow oil to drain. Screw in plug and fill in oil after repair work has finished.
Changing oil:
Changing oil:
Oil change is necessary only after repairs or after changing a working pump. In this case drain oil and fill in oil as described above. Oil quantity see „Filling quantities – oil“ table.
Oil change is necessary only after repairs or after changing a swing pump. In this case drain oil and fill in oil as described above. Oil quantity see „Filling quantities – oil“ table.
Fig. 3-73:
Fig. 3-74:
3-74
BA RH340(3 725 090.00)-EN
