OPERATING INSTRUCTIONS RH 340 Electric Inspection and servicing PUMP TRANSFER GEARBOX Read and observe: "Inspection and servicing - Safety instructions.
Checking the gearbox oil level / Topping up with oil Check oil level only when gearbox is cold. Heated oil may result in inaccurate measurements. Pull out and wipe dipstick (1, Fig. 3-70:).
Read and observe: "Inspection and servicing Safety instructions. Switch off the electric motor The gearbox housings may be hot, too. Secure the machine as described in the "Securing the machine" section. Protect the skin from contact with gearbox oil. Skin contact with cooling liquid is a potential health hazard. Wear protective gloves and firm working clothing.
Push dipstick all the way in and withdraw again. The level should reach up to between the markers; top up if necessary.
Fig. 3-70:
BA RH340(3 725 090.00)-EN
3-71
