OPERATING INSTRUCTIONS RH 340 Electric Inspection and servicing Breather filter Read and observe the "Inspection and servicing - Safety instructions" chapter.
Replacing the filter elements The breather filters (20, Fig. 3-46:) ensure venting of the hydraulic oil reservoir at varying hydraulic oil levels.
Switch off the electric motor. Risk of scalding caused by hot hydraulic oil. The hydraulic oil reservoir itself may also be hot. Avoid skin contact. Skin contact with hydraulic oil may cause skin injury. Wear protective gloves and firm working clothing. Fig. 3-46:
Unscrew screws (21). Remove holder (22) and withdraw filter element (20). Check filter element and replace, if required.
BA RH340(3 725 090.00)-EN
3-57
