OPERATING INSTRUCTIONS RH 340 Electric OPeration Regulating the travelling speed Travelling on level ground: Regulate the travelling speed with
Travelling uphill and downhill Read and observe the "Travelling Safety instructions" chapter.
pedals (112 and 113, Fig. 2-90:) set the first (slow) range or the second (fast) range with switch (71, Fig. 2-91:). Change speed range only when the excavator is stationary.
Depress padals (112 and 113, Fig. 2-90:) fully to the limit stop. When travelling downhill, the travel retarder valve acts as a speed limiter. The travel retarder valve works correctly if pedals (112 and 113) are fully depressed down to the limit stop. Should the travelling speed become too high when travelling downhill release pedals (112 and 113) to stop the excavator.
Fig. 2-90:
Fig. 2-91:
BA RH340(3 725 090.00)-EN
2-73
