Technical description Crusher housing and substructure The housing of the crusher plant and the substructure are manufactured from wear resistant material and in welded construction. The crusher housing is screwed to the substructure. Welded guidings in the pan warrant a faultless run of the chain. There is a device for a customer sided water spray system at the crusher housing (see Figure 7).
Impact roll
Height adjustment
The impact roll is also designed in welded construction. The roll is fastened and balanced on the crusher shaft with clamping elements. The impact roll is shifting in bearing housings and spherical roller bearings. Spacing plates are available for adjusting the passage height between the roll and the conveyor. The height adjustment is by means of hydraulic cylinders which are powered either by a hydraulic pump (hand pump) or by valves. The roll height adjustment will be realized by the customer. (Find more details on the following pages and in chapter 6 - "OperationRoll height adjustment".)
Figure 8: Impact roll 32Nm Torque
without V-belt pulley
300Nm Torque
Detail X
26
1 2 3 9 10 14 17 20 26
Impact roll Crusher shaft Bearing housing Spacing plate 40mm Spherical roller bearing Tensioning nut Cone grease nipple Clamping element Spacing plate 20mm For parts not listed here, please refer to the spare part list supplied
Object-No.: 55278500000000
