Technical data This chapter contains the most important technical data on the crusher plant. Furthermore the crusher plant will be described. Further data can be found in the spare part lists and in the separate operating manuals for the individual components such as e.g. motors. At the end of this chapter you will find information on bolt tightening torques; greases, etc.. Read this chapter carefully and pay attention in particular to the safety advices.
Technical data sheet General
Dimensions
Impact roll crusher
Object-No.: 55278500000000
Feeding material: Final product size: Throughput: Total weight:
Coal 0 - 150 mm + oversize approx. 3500 t/h approx. 15230 kg
Length: Width: Height:
approx. 3000 mm approx. 2570 mm approx. 1415 mm
Impact roll diameter: Impact roll width: Passage height under roll: R.P.M: Circumferential speed: Impact elements: Drive power:
840 mm 1480 mm 194 - 274 mm 530 rpm 23,3 m/s 6 pcs. 350 HP
