OPERATING INSTRUCTIONS RH 340 OPeration Fig. 2-55: No.
Element
Function
81
Switch
Mode
82
Switch
Superstructure hol- Blocks the superstructure ding brake
Symbol
Switches between two swing modes: to the left = 100%; to the right = 70%
Actuate switch only when the excavator is stationary. Do not use as service brake. 83
Switch
Windscreen wiper
Activates permanent / intermittent wiping
84
Switch
Screen washer
Activates the wipe / wash function
85
Switch
Floodlamps
Switches on the floodlamps on the driver´s cab
86
Switch
Floodlamps
Switches on the floodlamps on the driver´s cab roof
87
Switch
Floodlamps
Switches on the floodlamps on the hydraulic oil cooler
88
Switch
Floodlamps
Switches on the floodlamps on the counterweight
BA RH340(3 720 790.01)-EN
2-39
