OPERATING INSTRUCTIONS RH 340 Inspection and servicing CRAWLER TRACKS
To clean the tracks: Â raise one side of the excavator with the working equipment and allow track to turn;
Cleaning Clean tracks, track and support rollers, sprockets and idlers regularly and whenever required. Cleaning is especially important in winter to prevent
the tracks from being thrown off
oil from leaking out of track and support rollers, sprockets and idlers
excessive wear
the track from breaking.
 clean the side member supporting the track;  clean track and support rollers (1 and 2 ,Fig. 3-86:) thoroughly;  clean the sliding planes on the idler guides.
Fig. 3-86:
3-78
