OPERATING INSTRUCTIONS RH 340 Inspection and servicing Filling in hydraulic oil
 The oil level is also displayed on the BCSscreen (2, Fig. 3-62:).
Fill in hydraulic oil by means of the service station (Fig. 3-60:).
 Vent the hydraulic system.
 Unscrew cap of express coupling (10).
 Check the oil level in the hydraulic oil reservoir. Top up with oil, if required.
The use of the hose line is described under "hose line for oil changes".
 Unscrew the hose line. The express coupling closes automatically.  Screw protective cap back in place.
Fig. 3-60:
 Connect filling hose express coupling of the service vehicle. Fill in hydraulic oil until the oil level lies between the ½ and the ¾ marks of the inspection glass (1, Fig. 3-61:) (oil grade see "Refilling quantities - Oil").
Fig. 3-62:
Fig. 3-61:
3-62
