OPERATING INSTRUCTIONS RH 340 Inspection and servicing Selecting oils and greases Use the recommended qualities only, matching viscosities with the temperature level.
After servicing To prevent corrosion, coat all bright metal parts with a grease film.
Filters
On completing work, re-install all protective devices.
Replace / clean all filter elements or filter cartridges within the specified periods.
Never switch on the electric motor while work is being done on the machine.
All filters are coordinated carefully with the equipment. Original Terex|O&K parts must be used to ensure smooth running and a long service life of the engine and the hydraulic units.
Carry out performance tests with the machine.
Sealing elements When dismantling parts, watch for sealing elements. Check sealing elements prior to installation and replace any that are even slightly damaged. When assembling, ensure a perfect fit. Oil-level check and oil change Position the machine horizontally. Change the oil when the machine is at operating temperature. Warm oil flows better and carries suspended particles (carbon or abraded matter) better. Lubricating Clean the lubricating nipple, then lubricate as scheduled.
