OPERATING INSTRUCTIONS RH 340 OPeration At low temperatures, bring the engines down to moderate speed, then activate all hydraulic functions for about 10 minutes (bring to service temperature). For further instructions, see section "Lubricants". If the BCS indicates problems with the cooling liquid temperature, engine oil pressure, coolant level, alternator or hydraulic oil filter control (with hydraulic oil at service temperature) light up: Lower the working equipment and shut off engines. Parts of the attachment may damage the machine if they are moved into extreme positions (see illustrations Fig. 2-109: toFig. 2-113:). Work carefully, avoiding extreme positions of this kind.
Fig. 2-111:
Fig. 2-112: Fig. 2-109:
Fig. 2-110:
BA RH340(3 720 790.01)-EN
Fig. 2-113:
2-71
