SECTION 03 - TECHNICAL SPECIFICATIONS
OUTFIT WITH CLAMSHELL BUCKET Placing boom
Dipper
mm in
2000
78.74
2300
90.55
2600
102.36
A Maximum loading height
mm
in
5600
220.47
5700
224.41
6000
236.22
C Maximum depth
mm
in
5900
232.28
6200
244.09
6500
255.90
F Maximum outreach
mm
in
7100
279.53
7300
287.40
7600
299.21
H Front swing radius
mm
in
2300
90.55
2200
86.61
2300
90.55
K Minimum loading height
mm
in
2100
82.68
1800
70.87
1500
59.05
