4 - ASSEMBLY
29. Start the engine and operate the controls of the backhoe attachment to bleed air from the hydraulic system and to check if the hammer system operates correctly. 30. Adjusting the oil delivery to the hammer system 1.
Place the accelerator knob/lever in full speed position
2.
Press down the hammer control pedal (9) to operate the hammer
3.
Release the hammer control pedal (9) to stop the hammer’s operation
4.
According to the requirements of the recommended delivery, adjust the delivery regulator (R) of the hammer control valve (1)
NOTE: make sure to abide by the recommended delivery and to always obey the Manufacturer’s times and indications. For some auxiliary attachments, excessive delivery may cause damage. NOTE: do not operate the hammer on a telescopic arm unless the dipper is completely retracted and blocked in transport position.
RAIL16TLB0440CA
21
13 EN
