OPERATING INSTRUCTIONS
2
3
Your CASE Dealer can do this for you. Once this operation has been performed, a special access code has to be entered each time you start the engine.
1
IMPORTANT: Once the code has been entered, do not forget it, as it can not be changed without consulting your CASE Dealer.
Entering the code 1. Place the starter switch key in the "ON" position.
4. Once all four digits have been entered, press button (3) for the code to be entered in the system. The audible alarm device will sound. 5. To finish entering the code, place the starter switch key in "OFF" position. IMPORTANT: Remember to keep careful note of the code number, because if you forget it, it will not be possible to enter a new one without consulting your CASE Dealer.
CD00E077
2. The message "Password" and four boxes will appear on the display screen.
83
TRIM THIS EDGE RIGHT PAGE
TRIM THIS EDGE
CD00E078
3. To register the code (example: 1234), press the number of times corresponding to the first figure (example: 1 time) on key (1) then press key (2) in order to pass on to the second figure. Press the number of times corresponding to the second figure (example: 2 times) on key (1) then press key (2) to pass on the third figure. Repeat the procedure for the third and fourth digits.
Template Name: OM_1_col Template Date: 1994_04_29
To prevent the machine from being stolen it is possible to use the anti-theft system, which makes it necessary for a special code to be entered before the machine can be operated.
Alt= to hide template information Alt+ to display template information
ANTI-THEFT DEVICE
