LUBRICATION/FILTERS/FLUIDS
SWING REDUCTION GEAR Service specification Template Name: OM_1_col Template Date: 1994_04_29
Oil level check ............................................................................... Every 250 hours Oil change ................................................................................... Every 1000 hours (after the first 250 hours during the run-in period) Grease ........................................................................................ Every 2000 hours Oil capacity .............................................................................................. 10.5 litres Oil type ......................................................................... See "Fluids and lubricants"
Level
Draining and refilling
1. Park the machine on flat, horizontal ground. Stop the engine and remove the starter switch key.
1. Park the machine on flat, horizontal ground. Stop the engine and remove the starter switch key. 2. Remove the dipstick (2) and the filler plug (1).
TRIM THIS EDGE
2
1
Alt= to hide template information Alt+ to display template information
3
CD02A019
CD01K025
3. Place a receptacle of a suitable capacity under the upperstructure and remove the drain plug (3). 4.
Allow the oil to drain.
NOTE: The oil takes a relatively long time to drain.
CP98N043
2. Remove the dipstick (2). The oil should come up to the hatched area. If necessary, add more oil through the filler hole (1). 3.
IMPORTANT: Check the condition of the drained oil. If it contains metal filings or foreign matter, see your CASE Dealer. 5.
Install the drain plug (3).
Install the dipstick.
170
