HYDRAULIC BREAKER OR HIGH FLOW HYDRAULIC CIRCUITS (optional) Template Name: OM_1_col Template Date: 1994_04_29
Your machine has two types of auxiliary hydraulic circuit. One circuit is for single flow equipment, such as hydraulic breakers. The second circuit is for single flow or double flow continuous flow equipment, or double flow equipment such as concrete crushers. Consult your CASE Dealer for instructions on how to select the correct pressure for the optional tool.
Hydraulic breaker configuration 2
1
TRIM THIS EDGE
CD01K042
CS01K612
1. Make sure the necessary tool connections and then, using a hexagonal wrench, open the supply valves.
CS01K613
2. Make sure the selector blocks (1) and (2) are positioned as shown.
Alt= to hide template information Alt+ to display template information
2 3 1
CD00E072 CD01N020
3. Tilt the control (3) on the left-hand arm to the right for hydraulic breaker operation.
