INSTRUMENTS/CONTROLS
OPTIONAL TOOL FLOW SELECTOR BLOCKS
BD02D112
These blocks make it possible to select the correct hydraulic circuit for the optional tool.
TRIM THIS EDGE
OPTIONAL TOOL SUPPLY VALVES
A24690
Located on the end of the arm, these two valves are used to ensure oil supply to optional tools. These valves have two positions.
CD00E056
CD00E055
Position “S” (closed): In this position, there is no supply of oil to the tool.
Position “O” (open): In this position, oil is supplied to the tool. 83
