INTRODUCTION
Valve for blade operation Manufacturer Operating pressure Secondary pressure Operating angle Weight
Kawasaki Heavy Industries, Ltd. 3.92 MPa (569 psi) 0.64 – 2.45 MPa (92.8320 – 355 psi) primary short type 10° 1.0 kg (2.205 lb)
Remote control valve for offset operation Manufacturer Operating pressure Secondary pressure Operating angle Weight
Kawasaki Heavy Industries, Ltd. 3.92 MPa (569 psi) 0.64 – 2.45 MPa (92.8320 – 355 psi) primary pressure short type 12° 1.7 kg (3.748 lb)
Operation remote control valve control diagram
SMIL15CEX4380FB
1
Ports 1, 3 1 2 3 4
5 6 7
Push rod stroke [mm (in)] Operating angle [deg.] Secondary pressure [MPa] Operating torque [Nm]
Secondary pressure Independent operating torque (Port 1) Independent operating torque (Port 3)
51458637 15/03/2018
97
