LUBRICATION/FILTERS/FLUIDS
FLUID LEVELS EACH 10 HOURS OR DAILY SERVICES Engine Crankcase
Engine Coolant Level
Check oil level shortly after engine is warm and has been stopped. Remove the engine oil dipstick (2), and check oil level. If the oil level is below the minimum mark or above the maximum mark, do not operate the engine. Add oil if necessary through the filler neck (1).
Check coolant when engine is cold. Make sure coolant is visible in sight glass on expansion tank. If necessary, add coolant to the expansion tank. Turn the radiator cap slowly to remove pressure. Add coolant until level is at the bottom of the filler neck. NOTE: Never add anti freeze to cooling system without checking existing level of protection. Add coolant as necessary to bring it to the proper level. Tighten radiator cap.
2
1
Transmission Fluid Level Check the transmission oil level when the oil is hot and the system is charged. Place transmission in NEUTRAL, keep the engine idling and apply parking brake. Turn the handle counterclockwise to loosen the cap. Remove the cap and check oil level with the dipstick. Add oil as necessary to bring it to the proper level. Make sure the cap is tight on the filler neck after checking oil.
1. ENGINE OIL FILLER 2. ENGINE OIL DIPSTICK
Radiator
Fluid under pressure. Turn the cap slowly to relieve pressure before removing or until the pressure has been relieved. The coolant may boil over and cause personal injury.
WARNING:
!
ENGINE RUNNING
! WARNING
TRANSMISSION DIPSTICK
HOT LIQUID UNDER PRESSURE HAZARD Service when cool. 329044A1
90
WARM
