INSTRUMENTS/CONTROLS
INSTRUMENT PANEL INDICATORS A. ENGINE WATER TEMPERATURE
F. LOW TRANSMISSION OIL PRESSURE
When the light is ON, it means that the engine coolant has overheated which could be caused by:
When the light is ON, this indicates insufficient oil pressure that may be caused by: •
Use of oil with improper viscosity
•
Lack of coolant in the system
•
Low transmission oil level
•
Radiator cooling fins clogged
•
Defective switch and/or defective panel.
•
Radiator circuit clogged
G. LOW ENGINE OIL PRESSURE
•
Fan hydraulic drive system malfunction
•
Defective thermostat.
When the light is ON, this indicates insufficient oil pressure that may be caused by:
B. HYDRAULIC OIL TEMPERATURE
•
Use of oil with improper viscosity
When the light is ON, it means that the oil is overheated which could be caused by:
•
Low engine oil level
•
Engine oil leak
•
Use of oil with improper viscosity
•
Defective pressure switch
•
Low oil level.
H. LOW BRAKE OIL PRESSURE
C. TRANSMISSION OIL TEMPERATURE
When the light is ON, this indicates insufficient oil pressure that may be caused by:
When the light is ON, it means that the oil is overheated and its probable causes are: Low oil level
• • •
Pump abnormalities Air in the brake system Oil leak on brake lines
•
High oil level
•
Defective pressure switch.
•
Transmission hydraulic oil circuit troubles.
I. AIR FILTER RESTRICTION
•
Suction line filter clogged
•
When the indicator remains on constantly, the air filter element is clogged and it will be necessary to clean or replace it.
D. PARKING BRAKE When the light is ON, it means that the brake is actuated.
•
E. LOW BATTERY CHARGE
J. HYDRAULIC OIL FILTER RESTRICTION
When this light is ON, with the engine running, indicates defects in the charging system, caused by: •
Defective alternator
•
Charging resistor damaged
Defective switch and/or defective panel.
When the indicator remains on constantly, the oil filter element is clogged and it will be necessary to replace it. K. TRANSMISSION OIL FILTER RESTRICTION When the indicator remains on constantly, the oil filter element is clogged and it will be necessary to replace it.
42
