80
3550
AS REQUIRED
37. FUEL FILTERS Draining the condensation
Operations to be performed when the relevant indicators are activated:
Operation to be performed when the blue indicator on the monitor panel comes ON, indicating the requirement for the draining of water from the fuel filter.
1. Indicator - hydraulic oil filter clogged 2. Indicator - engine air cleaner clogged
D350M0063
3550-M005
35. ENGINE AIR CLEANER CLOGGED Clean the cartridges Operation to be performed when indicator 1, located on the instrument board indicates that the air cleaner is clogged. See operation no. 27.
Draining condensation Open the left upper panel of the engine compartment, perform the draining of the water and sediments from the fuel filter through the draining valve indicated. With engine inoperative, loosen the valve located under the filter about 4 full turns and move it downward about 2 cm. Let any water and sediment flow until clean fuel only gets-out. Push the valve upward and tighten, avoiding overtightening.
36. OIL FILTER ON EQUIPMENT HYDRAULIC CIRCUIT RETURN Replace the filtering cartridge WARNING Fluid under pressure. Turn the cap slowly to release the pressure before removing it.
Operation to be performed when indicator 3 on the instrument board comes ON indicating that the return oil filter is clogged. See operation no. 19.
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
D350M0123
