40
3550
- Sling the cab protection structure using lifting chains or cables in the point indicated in the figure and attach them to a hoist. - Remove securing screws 1, from the protection structure. - Repeat the operation on the opposite side of the machine. - Lift the structure and move it away from the machine.
- Remove the screws of the right and left front supports under the right and left front mudguard, as indicated.
1
D350M0118
D350M0054
- Remove the screws of the right and left rear supports reaching them from the rar side of the machine in the zone under the cab, as indicated.
WARNING Make sure that the cables are anchored to a point strong enough to support the load to be applied. keep all bystanders away from the anchoring point of cables and chains.
WARNING Avoid kinking chains or steel cables. Always wear protective gloves to handle cables and chains. D350M0119
- Remove the screws of the four supports, two at the front and two at the rear, securing the cab to the frame.
- Lift the cab using a hoist.
REINSTALLATION OF THE CAB To reinstall the cab, reverse the sequence used for the removal, described here above.
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
