___________________________________ LUBRICATION / FILTERS / FLUIDS
Cleaning Cooling System Drain, flush, and refill the engine coolant every 2000 hours of operation or each year, whichever occurs first. Clean the system and replace the coolant if the coolant becomes dirty or has the color of rust. DO NOT remove the radiator cap if the coolant is hot.
H04113
3. Add cleaning solution to the cooling system and fill the cooling system w i t h c l e a n w a t e r. F o l l o w t h e directions included with the cleaning solution. 4. After you drain the cleaning solution, flush with clean water. 5. Check the hoses, elbows and water pump for leaks.
1. Use a suitable container to drain the coolant. Remove the radiator cap. Open the radiator drain valve and open the engine block drain valve (1).
TRIM THIS EDGE
6. Make sure that the outside of the engine and radiator is clean. 7. Fill the cooling system until the coolant level is up to the top of the radiator cap opening. 8. Fill the coolant reservoir up to the FULL mark on the reservoir. 9. Start the engine and increase the temperature of the engine coolant. When the coolant is at operating temperature, stop the engine and allow to cool. Check the coolant level at the coolant reservoir only. Do not remove the radiator cap.
1
10. Dispose of drained coolant responsibly. Do not pour on ground or down drain.
B877256W
83
TRIM THIS EDGE
RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
!
WARNING: Hot coolant can spray out if radiator cap is removed. To remove radiator cap: Let system cool, turn to first notch, then wait until all pressure is released. Scalding can result from fast removal of radiator cap. Check and service engine cooling system according to maintenance instructions. SA023
Alt= to hide template information Alt+ to display template information
2. After all coolant is removed, close the drain valve.
