OPERATING PROCEDURE (CONT’D) Boom Swing Figure 174
Figure 171
NA1433B
NA1432
The boom swing allows the operator to offset the boom and dig close to buildings and other structures [Figure 174].
NA1420B
Figure 173
NA1434B
Slew the upperstructure, swing the boom to the right [Figure 171], center [Figure 172] and left [Figure 173] to dig a square hole the width of the machine without repositioning the excavator.
99 101 of 254
E42 Operation & Maintenance Manual
Dealer Copy -- Not for Resale
Figure 172
