AIR CLEANER SERVICE
A
Standard Replace the large (outer) filter element only when the red ring shows in the window of the condition indicator (Item 1) [A]. NOTE: Before replacing the filte element, push the button on the condtion indicator (Item 2) [A], start the engine. If the red ring does not show, do not replace the filter element.
1 2
Replace the inner filter every third time the outer filter is replaced or when the red ring still shows in the indicator window after the outer fiolter has been replaced.
P–00371
B
Optional
B–12914
Service the air cleaner as follows:
C
Remove the dust cover wing nut [C].
Dealer Copy -- Not for Resale
It is important to change the air filter element only when the service code (on the instrument panel) shows the symbols as in the figure [B].
CD–10843
Remove the dust cover [D].
D
CD–10844 53 of 98
–35–
853 Bobcat Loader Operation & Maintenance Manual
