ELECTRICAL SYSTEM (Cont’d)
A
Battery Removal And Installation
Batteries contain acid which burns eyes and skin on contact. Wear goggles, protective clothing and rubber gloves to keep acid off body. B–03709
In case of acid contact, wash immediately with water. In case of eye contact get prompt medical attention and wash eye with clean, cool water for at least 15 minutes.
B
If electrolyte is taken internally drink large quantities of water or milk! DO NOT induce vomiting. Get prompt medical attention.
Open the rear door. Disconnect the negative (–) battery cable first [A].
1
Disconnect the positive (+) battery cable. Remove the battery holddown clamp (Item 1) [B]. Remove the battery from the loader.
B–11812
Always clean the terminals and cable ends when installing a new battery [C].
C
When installing the battery in the loader,do not touch any metal parts with the battery terminal posts. Connect and tighten the battery cables. Connect the negative (–) cable last to prevent sparks.
P–09590
59 of 80
–39–
